Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

contacto

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Quantidade de ordem mínima :	1 peça	Detalhes da embalagem :	254 × 90 × 210
Tempo de entrega :	7 semanas dias	Termos de pagamento :	L/C, D/A, D/P, T/T, Western Union
Habilidade da fonte :	5000PCS/MONTHS

Lugar de origem:	China	Marca:	MF
Certificação:	CCC, CE, EMC, ETL, GS, RoHS, SAA	Número do modelo:	MF-LI-B2-D

Informação detalhada
Fonte de luz:	LED	Cores disponíveis:	Vermelho (outra cor é opcional)
Intensidade:	≥32.5CD (Tipo B), Outros Opcional (10CD, 100CD, etc.)	Output horizontal:	360
Divergência vertical:	≥ 10	Características instantâneas:	Queima constante/20/30/60 ajustável
Modo de funcionamento:	Cano principal & suporte por (outros modos são opcionais)	Duração de vida do LED:	Operação como Opção. Experiência de Vida do LED (Horas) >100
Tensão de Operação:	C.C. (48VDC) &AC (110-240VAC) ou outro	Potência:	5W
Proteção de circuitos:	Integração	Material do corpo:	policarbonato
Material Base:	Alumínio de fundição por impressão
Destacar:	UV-Resistant Aviation Obstruction Light , Adjustable Aviation Obstruction Light

Descrição de produto

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Features:

1. High reliability

Automatic switching of main and backup lamps to ensure continuous marking.

Lightning protection, in accordance with IEC standard.

Integrated circuit protection against abnormalities.

2. Strong environmental adaptability

IP66 waterproof rating.

Operating temperature -40ºC to 65ºC, storage temperature -55ºC to 70ºC.

Resistant to wind speed up to 240km/h.

3. Flexible Design

Support DC48V and AC110-240V power supply.

Built-in light control, automatic switching.

Multiple mounting methods for ease of use.

Key Advantages:

1. High Reliability

Main & standby mode ensures continuous operation.

Built-in surge protection.

Long LED life (>100,000 hours).

2. Durability

IP66 waterproof rating.

UV-resistant polycarbonate cover.

Corrosion-resistant die-casting aluminum base.

3. Adaptability

Dual power supply (DC & AC).

Automatic day/night operation.

Optional GPS sync and solar power.

Light Source	LED
Available Colors	Red (Other color is optional)
Intensity (cd)	≥32.5cd (type B), others optional (10cd, 100cd, etc)
Horizontal Output (degrees)	360
Vertical Divergence (degrees)	≥10
Flash Characteristics	Steady-burning/20/30/60 adjustable
Working Mode	Main & stand by (other modes are optional)
Operation Mode	Dusk-to-dawn Automatically as standard. 24 hours operation as option.
LED Life Experience (hours)	>100,000
Operating Voltage	DC(48VDC) & AC(110-240VAC) or others

Power (W)	5
Electrostatic	IEC61000-4-2 Contact discharge 8kV
Circuit Protection	Integrated
Body Material	Polycarbonate
Base Material	Die-casting aluminum
Mounting	3/4 inch pipe thread or D140mm×M10*3
Dimension (mm)	254×90×210 or 254×165×250
Weight (kg)	1.5 or 2
Product Life Expectancy	10 years plus

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge 0

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge 1

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge 2

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge 3

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge 4

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge 5

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge 6

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge 7

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge 8

SERVICE
Ming Feng lighting CO.,Ltd providing the OEM & ODM service for all the partners all around the world, Our LED light is in high quality standard at reasonable and competitive price, our designer and engineer help our LED light in tasteful design and excellent performance.We are able to offer our valuable clients:
★ OEM/ODM Serivce
★ Photometric/IES file
★ Dialux simulation design
★ PCB Design/Driver Design
★ Heat Management/Optical Design
★ Industry Design
★ Market Support
★ 3D Printing
★ Multiple Listing/Private Label.
